What is a VFD? (Variable Frequency Drive)


 What is a VFD? (Variable Frequency Drive)

Today you will learn about VFDs. Specifically, what they are and when we use them with automation and PLCs.


What exactly is a VFD? Well, it stands for Variable Frequency Drive. They are used for running an AC motor at variable speeds or let them ramp up their speed to give them a smooth startup.


Some people simply call them drives. They work by adjusting the frequency of the motor to adjust the rpms.

Variable Frequency Drives Explained - VFD basics. In this video we take a look at variable frequency drives to understand how they work in electrical engineering and power electronics. We look at where and why to use a VFD or VSD, alternating current, direct current, single phase, three phase, frequency, rectifier, DC bus, inverter, capacitor, pwm, pulse width modulation.

Discover how variable speed technology and inverter compressors combine to create the ultimate in HVAC efficiency. Check out Danfoss’s case stories to see how their customers have benefitted or dive a bit deeper into how the technology works with a free eLesson.

In this video, we will learn about VFD and its applications. We will also cover in detail the converter and the DC link.


Induction or alternating current electric motors rotate at a rate that is set by the number of poles inside the motor itself, and the power supplied.


The frequency is directly related to the RPM of a motor. The higher the frequency, the faster the RPM or the higher the engine rotation speed.


In the United States, electric power utilities provide alternating energy with a frequency of 60Hz. A standard two-pole AC motor operating at this frequency provides a nominal rotation of 3600 RPM.


If an application does not require an electric motor running at full speed of 3600 RPM, which is very common, a few solutions exist:


– Using a mechanical speed reducer decreases the output speed by increasing torque – the output gear has more teeth than the input gear. They require lubrication, provide no flexibility, are subtle to vibration and noise, and are not suitable when shafts are distant.


– Adding more sets of poles reduces the speed without altering it electrically. Currently, there are transistor systems that allow poles inside motors to be turned on and off. However, those systems can be complex and do not provide fine control.


– Using a Variable Frequency Drive (VFD) can be configured and fine-tuned to generate a ramp, frequency, and voltage so that the motor operates according to the load requirements (desired speed and voltage).


An important feature of the variable frequency drive is that as the motor speed requirements in a given application change, the drive can simply raise or lower the motor’s speed in order to meet new operating requirements.


The use of VFDs is widespread in numerous industrial and commercial applications.

– In industrial applications, VFDs are used to control from extruders, and electric cranes, to roller coasters, and mechanical bulls, with so much in between!


– In commercial applications, VFDs are widely used in pumps to control flow and even volume in a tank, as well as in the HVAC industry, being considered green technology.


Ultimately, a VFD varies the frequency supplied to an AC motor in order to control its speed; Allowing a smooth startup, and adjusting motor speed as the application requires.


Let’s dive into the How does a VFD work?


1) A six-pulse rectifier or converter is where the three-phase alternating current gets converted into direct current by the use of diodes.


When we connect a three-phase alternating current to the converter:


– When phase A is greater than phase B or C voltages, this diode opens, allowing current to flow,

– When phase B becomes greater than phase A, then it is phase B diode that opens while phase A diode is closed,

– The same is true for C, as well as for the three diodes on the negative side of the bus.


That results in six pulses of currents as each diode opens and closes. The resultant waveform will look like this:


2) The DC bus is represented by only one capacitor and resistor on the diagram, but in reality, there are various capacitors and resistors associated in series and in parallel.


Since the capacitors are not charged, their impedance is very low. If we were to charge them, the initial inrush could damage the input power devices, or the rectifier/converter, in case the entry fuses didn’t interrupt the circuit.


So instead, we have a pre-charge circuit. Pre-charge is a current limiting circuit that slows the charge rate of the bus capacitors during power-up.


3) IGBT is the last step of the drive output: the DC to AC converter and our PWM output.


 What is a VFD? (Variable Frequency Drive)

Today you will learn about VFDs. Specifically, what they are and when we use them with automation and PLCs.


What exactly is a VFD? Well, it stands for Variable Frequency Drive. They are used for running an AC motor at variable speeds or let them ramp up their speed to give them a smooth startup.


Some people simply call them drives. They work by adjusting the frequency of the motor to adjust the rpms.

Variable Frequency Drives Explained - VFD basics. In this video we take a look at variable frequency drives to understand how they work in electrical engineering and power electronics. We look at where and why to use a VFD or VSD, alternating current, direct current, single phase, three phase, frequency, rectifier, DC bus, inverter, capacitor, pwm, pulse width modulation.

Discover how variable speed technology and inverter compressors combine to create the ultimate in HVAC efficiency. Check out Danfoss’s case stories to see how their customers have benefitted or dive a bit deeper into how the technology works with a free eLesson.

In this video, we will learn about VFD and its applications. We will also cover in detail the converter and the DC link.


Induction or alternating current electric motors rotate at a rate that is set by the number of poles inside the motor itself, and the power supplied.


The frequency is directly related to the RPM of a motor. The higher the frequency, the faster the RPM or the higher the engine rotation speed.


In the United States, electric power utilities provide alternating energy with a frequency of 60Hz. A standard two-pole AC motor operating at this frequency provides a nominal rotation of 3600 RPM.


If an application does not require an electric motor running at full speed of 3600 RPM, which is very common, a few solutions exist:


– Using a mechanical speed reducer decreases the output speed by increasing torque – the output gear has more teeth than the input gear. They require lubrication, provide no flexibility, are subtle to vibration and noise, and are not suitable when shafts are distant.


– Adding more sets of poles reduces the speed without altering it electrically. Currently, there are transistor systems that allow poles inside motors to be turned on and off. However, those systems can be complex and do not provide fine control.


– Using a Variable Frequency Drive (VFD) can be configured and fine-tuned to generate a ramp, frequency, and voltage so that the motor operates according to the load requirements (desired speed and voltage).


An important feature of the variable frequency drive is that as the motor speed requirements in a given application change, the drive can simply raise or lower the motor’s speed in order to meet new operating requirements.


The use of VFDs is widespread in numerous industrial and commercial applications.

– In industrial applications, VFDs are used to control from extruders, and electric cranes, to roller coasters, and mechanical bulls, with so much in between!


– In commercial applications, VFDs are widely used in pumps to control flow and even volume in a tank, as well as in the HVAC industry, being considered green technology.


Ultimately, a VFD varies the frequency supplied to an AC motor in order to control its speed; Allowing a smooth startup, and adjusting motor speed as the application requires.


Let’s dive into the How does a VFD work?


1) A six-pulse rectifier or converter is where the three-phase alternating current gets converted into direct current by the use of diodes.


When we connect a three-phase alternating current to the converter:


– When phase A is greater than phase B or C voltages, this diode opens, allowing current to flow,

– When phase B becomes greater than phase A, then it is phase B diode that opens while phase A diode is closed,

– The same is true for C, as well as for the three diodes on the negative side of the bus.


That results in six pulses of currents as each diode opens and closes. The resultant waveform will look like this:


2) The DC bus is represented by only one capacitor and resistor on the diagram, but in reality, there are various capacitors and resistors associated in series and in parallel.


Since the capacitors are not charged, their impedance is very low. If we were to charge them, the initial inrush could damage the input power devices, or the rectifier/converter, in case the entry fuses didn’t interrupt the circuit.


So instead, we have a pre-charge circuit. Pre-charge is a current limiting circuit that slows the charge rate of the bus capacitors during power-up.


3) IGBT is the last step of the drive output: the DC to AC converter and our PWM output.
