Homemade Tool - UNIVERSAL LED TESTER

 Homemade Tool - UNIVERSAL LED TESTER

Today in this instructable we are going to make a simple but very useful Diy project a SIMPLE LED TESTER.

Have you working with LED based project?

Yes of course we all are working with LED based projects, we need LEDs its an essential part of our project like LED cube, LED chaser Lights etc.... are some of the examples.

The reason I came up with this idea is yesterday I was just working with an LED based project for my college after completing the project I realized that some of the LEDs that I am using is already dead. My whole project gone to waste bin.

So, I come up with this idea to test my LEDs if it is work or not. This LED tester is simple to make, it may take 5 minutes or less and it's super cheap.

Firstly we need to collect all the parts that we need to do this project.

You don't need many parts to do this project. Its small and cheap components, even may it is already have in your hand if you are a maker.

Here Is The Parts You Need To Collect:

9volt Battery

9volt Battery connector

1k Resistor

General purpose PCB(a small piece needed)

Female Headers (two ports)

Hookup wires

Other Tools Used In This Project:

Soldering iron.

Soldering Wire.

Hot Glue / Instant Adhesive Glue.

I think that's all we needed.

After collecting all the parts lets jump to next step.

In this step we need to solder all the components on the PCB and connect each other. Take a look at the schematics shown i above images and solder the components correctly.

After soldering all the components each other lets go to next step.

Now in this step we just need to glue the battery connector to the other side of the PCB. Use a hot glue gun or instant adhesive glue.

Take a look at the above images and glue it perfectly.

Here I used an instant adhesive glue in this project.

Well that's all, we done. Now just take your LED and plug it in your DIY LED TESTER to check the led working or not.
