on video IoT Based Water Level Monitoring system using ESP32 Blynk & Ultrasonic Sensor

 In this IoT internet of things project, I have shown how to make the IoT based water level monitoring system using ESP32 Blynk and ultrasonic Sensor. For the LOW water level, the alarm will start and you will get a Blynk notification on the smartphone through the internet. Also, you can monitor the water tank level on OLED.

For this IoT-based water level indicator project, you can use any ultrasonic sensor as the water level sensor in the tank. You can always monitor the tank water level on OLED and if the ESP32 is connected to WiFi, you can monitor the water level from anywhere in the world on Blynk IoT App.

During this video, I have made the circuit on zero PCB using the PCB layout, and also shared the wireless water tank level indicator circuit and source code.

The alarm will ring when the tank is full and when the water level drop below the threshold limit.

I have not connected relays to the control pump but if you want you can connect a relay instead of the green LED to control a pump.

Important points: 1. For the SR04M waterproof ultrasonic sensor minimum measure distance is 25cm, so the distance between the sensor and the full tank water level must be greater than 25cm. 2. As per the logic, the ultrasonic sensor will only calculate the water level if the measured distance between the predefined values for the empty tank and full tank. 3. Define all the distance values in cm. 4. You can press the button to stop the buzzer. 5. You can either give AC supply, or 5V DC supply as shown in the video. 6. Please watch the complete video, otherwise you may face some issues. **Please take proper safety precautions while working with high voltages. This IoT-based ultrasonic water level sensor will help you to maintain the water level in the tank, also it is very useful to save energy and water resource.
