on video How To Make Simple 12v Battery Charger Circuit At Home

 we are going to show you making a 12v battery charger circuit. There are many kind of battery charger circuit, half wave battery charger circuit is one of them. To make this circuit, you don’t need enough electronics component. You can make this circuit at home easily.

Component list have to been given below.

Component List :

1. Transformer – 12.0.12 Volt

2. Capacitor – 2200uf/25v

3. Diode – 1N5399

4. Resistor – 1 K

5. LED – 5mm

6. Battery – 12v

7. Soldering Iron

8. Power Source  - AC 220v

Simple 12v battery charger circuit.

Parts used: 12v AC transformer, Bridge Rectifier,1000mf/16v capacitor,

LM317 voltage regulator,2.2kohms and 220ohm resistors.

I forget to show in video,A diode 1n4007 is good to be add on positive pole.
